名称
棉线
- 人气：330
- 简介
棉线<br>[产品说明]:本产品主要由棉纱和化纤组成，用于电线电缆填充，也可用于橡胶电缆外层纺编织。<br>[应用方式]:主要作为填充，使线缆可以达到真圆，同时可以增加线缆的弯曲性能。<br>一、主要技术指标：
内容
棉线
Cotton thread
[产品说明]: 本产品主要由棉纱和化纤组成，用于电线电缆填充，也可用于橡胶电缆外层纺编织。
Product Description: This product is mainly made up of cotton and chemical fiber, used for filling in wire and cable, can also be used for braiding in rubber cable.
[应用方式]: 主要作为填充，使线缆可以达到真圆，同时可以增加线缆的弯曲性能。
Application: Mainly as a filler to make cable can meet true circle, at the same time can increase the bending properties of the cable.
一、主要技术指标：
Main specification:
|
产品规格 Specification |
断裂强度 Breaking strength (kg/0.5M) |
比重(g/m)公差15% proportion (g/m) tolerance 15% |
断裂伸长率 Elongation atbreak (%) |
|
5支/1股
5 piece/1 strand |
≥2.5 |
0.118±0.017 |
≥10 |
|
5支/5股 5 piece/5 strand |
≥2.5 |
0.590±0.088 |
≥10 |
|
5支/6股 5 piece/6 strand |
≥2.5 |
0.708±0.106 |
≥10 |
|
5支/10股 5 piece/10 strand |
≥2.5 |
1.180±0.177 |
≥10 |
|
7支/1股 7 piece/1 strand |
≥2.5 |
0.084±0.012 |
≥10 |
|
7支/5股 7 piece/5 strand |
≥2.5 |
0.420±0.063 |
≥10 |
|
7支/6股 7 piece/6 strand |
≥2.5 |
0.504±0.075 |
≥10 |
|
7支/10股 7 piece/10 strand |
≥2.5 |
0.840±0.126 |
≥10 |
|
10支/1股 10 piece/1 strand |
≥2.5 |
0.059±0.008 |
≥10 |
|
10支/5股 10 piece/5 strand |
≥2.5 |
0.295±0.044 |
≥10 |
|
10支/6股 10 piece/6 strand |
≥2.5 |
0.354±0.053 |
≥10 |
|
10支/10股 10 piece/10 strand |
≥2.5 |
0.590±0.088 |
≥10 |
|
注：除以上规格外，可以根据客户特殊要求订做。 In addition to the above specifications, other special requirements can design according to customers |
|||
二、颜色：本色白，漂白，黑色和各种颜色。
Color: White, bleaching, black and other color
三、棉线特性：柔软性佳、重量轻、拉力好、耐温、无毒环保。本公司可根据客户之要求进行染色和绞合。
Characteristics: Good softness, light weight, good tension, temperature resistance, drug-free and environmental. Our company can dyeing and stranded according to customer's requirements.
四、包装方式：编织袋或纸箱包装。每包20-25KG.
Packaging: Woven bag or carton packaging, 20-25 kg per bag
